Your game loads the same .envy.json file the editor saves. Godot builds Control nodes from it, the browser builds elements from it, and neither needs generated UI code.
The EnvyUI node rebuilds the document from Panels, Containers and Labels at runtime, so focus, gamepad and input stay Godot's own. In Godot 4.6+, import .envy.json as a resource and edits show up while the game runs.
addons/envy_uiOne script renders the document to plain elements. The editor canvas uses the same renderer, so the canvas and the game can't drift apart.
envy-runtime.jsExport one HTML file with the runtime and your document inside. Send it to anyone who should click through the interface.
Click, use the arrow keys and Enter, or plug in a controller. On the boss fight, Esc opens the pause menu as an overlay.
Both take a few lines. The quick start walks through it.
Godotaddons/envy_ui into your project and enable the plugin.res://ui/. In Godot 4.6+ it imports as an EnvyDocument resource.var ui := EnvyUI.new() ui.document_path = "res://ui/the_last_hunt.envy.json" add_child(ui) ui.ui_event.connect(func(event, payload): if event == "new_hunt": start_new_hunt()) ui.set_data("player.hp", 212) ui.focus_first_button()
envy-runtime.js. It defines the global Envy.<script src="envy-runtime.js"></script> <script type="module"> const doc = await fetch("ui/the_last_hunt.envy.json").then((r) => r.json()); const ui = Envy.mount(document.getElementById("ui"), doc, { screen: "02 Main menu" }); ui.on("new_hunt", () => game.startHunt()); ui.setData("player.hp", 212); </script>
The same verbs on both sides.
| Properties | |
| document | An EnvyDocument resource (an imported .envy.json). Reloads while the game runs |
| document_path | Or a path to the .envy.json file |
| start_screen | Screen to show first. Defaults to the first screen |
| scale_mode | FIT scales the design resolution into the node and stretches to its aspect |
| autoplay | Play autoplay animations when a screen shows |
| use_sample_data | Start with the document's sample data |
| hot_reload | Pick up a re-imported document while the game runs |
| locale | Locale for translated text, like "de" or "pt-BR" |
| fonts | Family name to a Font resource, for fonts the document does not embed |
| cancel_closes_overlay | ui_cancel (Esc, gamepad B) closes the top overlay |
| Methods | |
| goto(screen, transition) | Show a screen by name or id |
| push(screen, transition) · pop() | Open a screen over the current one, close the top one |
| get_stack() · get_screen_names() | The open screens, every screen |
| set_data(path, value) | Set one data path, for example "player.hp" |
| merge_data(patch) · get_data(path) | Deep-merge a dictionary, read a value |
| play(anim) · stop(anim) · is_playing(anim) | Run the document's animations |
| set_locale(locale) · get_locales() | Switch language at runtime |
| get_control(name_or_id) | The Control built for a layer |
| focus_first_button() | Start keyboard and gamepad navigation |
| load_document(path) · load_resource(res) | Load another document |
| Signals | |
| ui_event(event, payload) | A button emitted an event |
| screen_changed(screen_name) | goto, push or pop ran |
| data_changed(data) | A button set or toggled data |
| document_reloaded | The document changed on disk and was reloaded |
| Entry point | |
| Envy.mount(host, doc, opts) | Mount a document into an element and run it. Returns a player |
| opts.screen · opts.data | First screen; initial data (defaults to the sample data) |
| opts.locale | Locale for translated text, or "pseudo" |
| opts.scaleMode | "fit" (default) or "none" |
| opts.autoplay · opts.gamepad | Autoplay animations; gamepad navigation (both on by default) |
| opts.respectReducedMotion | Skip screen transitions for people who ask for less motion |
| opts.onEvent · onScreenChange · onDataChange | Callbacks for events, screen changes and data actions |
| Player | |
| goto(screen, { transition }) | Show a screen by name or id |
| push(screen) · pop() · stack | Overlays, and the open screens |
| setData(path, value) · setData(patch) | Set one path, or deep-merge an object |
| getData(path) | Read a value, or all data |
| play(anim) · stop(anim) · isPlaying(anim) | Run the document's animations |
| setLocale(locale) · locales | Switch language at runtime |
| on(event, fn) · off(event, fn) · emit(event, payload) | Listen to events ("*" for all), or send one |
| layout() · destroy() | Rescale after a resize you manage, or unmount |
The Godot scene tree, the document and the browser's elements for The Last Hunt's main menu.
From the format spec. Both runtimes are tested against the same documents.
Embedded font assets work the same in both. For families a document does not embed, the web loads Google Fonts by name and Godot uses EnvyUI.fonts or a SystemFont.
Godot uses clip_children when the frame has a visible fill, otherwise it clips to the rectangle.
CSS blur on the web, StyleBoxFlat shadow_size in Godot (about blur × 0.6). Shapes have no shadow in Godot yet.
CSS flattens the group. Godot modulate multiplies each child, which shows where children overlap.
CSS backdrop-filter on the web, a screen-texture shader in Godot that is a little softer at large radii.
The web picks the nearest button by position; Godot uses its own search, so unusual layouts can differ. Escape closes overlays in Godot; on the web, gamepad B does.
